- User-FriendlyEasy-to-use and maintain; simply plug and print.
- AffordableReliable operations and high-resolution printing offered at a reasonable price.
- Highly Scalable: An all-in-one printing solution with upgradable options, ribbons, and software.
- Trusted security contact, contactless, and magnetic stripe encoding for high-standard digital security compliance with EMV. Equipped with a physical lock.
- Smart DesignCompact size with a unique design, ideal for limited workspaces.
- CapabilitiesThe CP55 is a high-quality printer with 300×300 dpi, edge-to-edge printing on various types of cards and thicknesses, and a wide range of ribbons.
- OperationAll-in-one ribbon cassette and cleaning roller simplifies ribbon loading and cleaning processes. The device features easily operated LED indicators, buttons, and an instant system status LCD.
- Performance: The built-in 64 MB memory facilitates the high-speed storing and processing of printing jobs.
- PersonalizationIt offers several ways to protect against card tampering and fraud by adding a hidden security feature with an ultraviolet (UV) ribbon and smart card encoding. It supports the secure global EMV standard, ensuring that cards are interoperable with the global payment infrastructure.
- Modularity Seamlessly upgrade to magnetic stripe, smart card encoders, and physical locks for trusted security. An additional feature of the Ethernet upgrade module enables the Heidi CP55-D printer to be networked for access by multiple users or from a central location.
Please contact +971551189793 or Email: info@cardlineuae.com for enquiries and prices for Heidi CP55-S Single-Side Card Printer in Dubai, Abu Dhabi, Sharjah, Ajman, Fujairah, Ras al Khaimah, Al Ain, and Um al Quwain—UAE, Middle East & Africa. Saudi Arabia, Bahrain, Qatar, Kuwait, Oman, Egypt, Iraq, Yemen, South Africa, Sudan, Kenya, Uganda, Libya, Djibouti, Seychelles, DR Congo, Comoros, Togo, Tanzania, Cabo Verde, Ethiopia, Eswatini, Tunisia, Burundi, Benin, Mauritius, Rwanda, Guinea, Zimbabwe, Somalia, Chad, Senegal, Zambia, Malawi, Guinea-Bissau, Mali, Nigeria, Botswana, Cameroon, Madagascar, Ghana, Angola, Morocco, South Sudan, and Congo.
Technical Specifications
Standard Features
Printing Method: Direct-to-card dye-sublimation/resin thermal transfer
Accepted Standard Sizes/Format: ISO CR-80 (3.375˝ L x 2.125˝W/85.6 mm L x 54 mm W)
Accepted Card Thickness: 0.38mm (15 mil) ~ 1.0mm (40 mil)
Resolution: 300 dpi (11.8 dots/mm)
Print Area: CR-80 (3.36˝ L x 2.11˝ W/85.3 mm L x 53.7 mm W)
CPU: AM3352 600 MHz
Printing Speed: Color (YMCKO): 170 cards/hour
Color (YMCKOK): 130 cards/hour
Black Overlay (KO): 360 cards/hour
Mono (Black): 720 cards/hour
Print Ribbon Options: Full-color with resin black and overlay panel, YMCKO, 250 prints/roll
Full-color with two resin black panels and overlay panel, YMCKOK, 200 prints/roll
Resin black with overlay panel, KO, 600 prints/roll
Mono (Black, Gold, Silver): 1,200 cards/roll
YMCUVO Blue: 200 prints/roll
Half YMC Full KO: 350 prints/roll
Input Hopper Card Capacity: 100 cards (200 cards with cover open)
Output Hopper Card Capacity: 40 cards (100 cards with option backside stacker)
Card Cleaning: Cleaning the roller with each cartridge
Memory ROM: 2MB, RAM: 64MB
Software: GET Identity (ID Card Design & Management Software)
Interface: USB 2.0, Ethernet Optional
Display: 2 Lines (16×2) LCD & LED
Power: Free Voltage (110/240V AC), 50 ~ 60 Hz, 45W
Dimensions: 486mm(W) x 208mm(H) x 166mm(D)
Operating Environment: Temperature: 20 ~ 35℃, Humidity: 20 ~ 80%
Weight: 6.0 Kg
Certification: CE, CB, FCC
Operating System Support for Printer Driver: Windows 7/8/10, Linux, Mac
Warranty: 24-month standard depot warranty | 24-month print head warranty
Kensington Lock: Back side
Field-Upgradable Options
Magnetic Stripe Encoder: ISO7811 (Track Ⅰ, Ⅱ, Ⅲ Read/Write) HiCo/LoCo
Contact Smart Card Encoder: ISO/IEC 7816-1,2,3,4: IC Cards with contacts
EMV Terminal Level 1 version 4.1
Contactless Smart Card Encoder: ISO14443 (Type A/B)
MIFARE®, MIFARE DESFire® iCLASS®
EMV2 2000 Level 1
Ethernet: TCP/IP 10/100 BaseT
Physical Lock: Top cover lock
