| Standard Features & Supplies |
| Print technology |
Dye-sublimation/resin thermal transfer |
| Print capabilities |
Single or dual-sided, rewritable technology |
| Print resolution |
300 dots per inch (dpi) (300 X 600, 300 X 1200) |
| Print, lamination, and tactile speed |
- Front side YMCK ribbon with front side lamination: Up to 210 cards per hour
- Front side YMCK-K ribbon with front side lamination and back side K: Up to 185 cards per hour
- Front side YMCK ribbon with lamination and tactile: Up to 195 cards per hour
- Dual-sided YMCK K ribbon with lamination and tactile: Up to 160 cards per hour
- Monochrome printing: Up to 1,100 cards per hour, single-sided
|
| Print speed |
- Input hopper: 125 cards
- Output hopper: 25 cards
- Reject hopper: 10 cards
|
| Card capacity |
Input hopper: 125 cards
Output hopper: 25 cards
Reject hopper: 10 cards |
| Card sizes |
Thickness: 0.010 inches to 0.040 inches (0.25mm - 1.016mm)
Dimension: ID-1, CR-79, CR-80 |
| Operating environment |
Temperature: 60°F to 95°F (15°C to 35°C)
Humidity: 20-80% RH – non-condensing |
| Physical dimensions |
L 23.8 in x W 10.6 in x H 20.4 in / 60.4 cm x 27 cm x 51.9 cm |
| Weight |
30 lbs (13.62 kg); varies with options |
| Connectivity |
USB and Ethernet |
| Warranty |
36 months |
Web browser support for
Instant ID as a Service |
Chrome - Preferred
Edge/Internet Explorer
Safari |
Operating system support for
printer driver |
Windows 10 versions, 32- and 64-bit
Windows 8.1, 32- or 64-bit
Windows Server 2019
Windows Server 2016
Windows Server 2012, R2, 64-bit |
| Optional Features & Supplies |
| Magnetic stripe encoding |
ISO 7811 three-track support (high- and low-coercivity)
JIS Type II single-track option |
| Multi-hopper |
Six compartment multi-hopper (six 125-card hoppers, 750-card total capacity) |
| WiFi |
WiFi types: 802.11g/n
Authentication modes: None, WPA2 Personal
Dual-band 2.4GHz and 5GHz |
| Smart card encoding |
Single wire or loosely coupled:
• Contact smart card encoding: ISO 7816 T=0 (T=1), Class A 5V (3V and 1.8V)
• Contactless smart card encoding: ISO 14443 A/B, ISO 15693, MIFARE,
MIFARE® DESFire EV1/EV2, HID Prox, iClass, iClass SE, iClass Seos, Felica |
| Color ribbons* |
Prefilled print ribbon cassettes:
- YMCKT 500
- YMCKT-KT 50
- KTT 750
- ST-KT 500
- GT-KT 500
Refil print ribbon kits:
- YMCKT 250/500
- ymcKT 650
- YMCKT-KT 350
- ymcKT-KT 435
- KT 1,000
- KTT 750
- YMCKF-KT 300
- YMCKL-KT 300
- YMCK** 500
- YMCK-K** 500
|
| Monochrome ribbons |
Refill print ribbon kits in black, white, blue, red, green, scratch-off, silver matte,
gold matte, silver metallic, and gold metallic: 1500 images |
| Overlays and films |
Prefilled print ribbon cassettes:
- Clear or holo topcoat: 1000 images
- DuraGard® clear or holo laminate (0.5, 0.6 or 1 mil): 350 images
- DuraGard® clear or holo laminate (1.0 mil): 300 images
- Clear DuraShield™ overlay**: 500 images
|
